DimethylEther

References

Equation of State

Jiangtao Wu, Yong Zhou, and Eric W. Lemmon. An Equation of State for the Thermodynamic Properties of Dimethyl Ether. J. Phys. Chem. Ref. Data, 40(2):023104–1:16, 2011. doi:10.1063/1.3582533.

Viscosity

Xianyang Meng, Jianbo Zhang, Jiangtao Wu, and Zhigang Liu. Experimental Measurement and Modeling of the Viscosity of Dimethyl Ether. J. Chem. Eng. Data, 57:988–993, 2012. doi:10.1021/je201297j.

Surface Tension

A. Mulero, I. Cachadiña, and M. I. Parra. Recommended Correlations for the Surface Tension of Common Fluids. J. Phys. Chem. Ref. Data, 41(4):043105–1:13, 2012. doi:10.1063/1.4768782.

Aliases

DIMETHYLETHER, DME

Fluid Information

Parameter, Value
General
Molar mass [kg/mol] 0.04606844
CAS number 115-10-6
ASHRAE class A3
Formula \(C_{2}H_{6}O\)
Acentric factor 0.196
InChI InChI=1/C2H6O/c1-3-2/h1-2H3
InChIKey LCGLNKUTAGEVQW-UHFFFAOYAU
SMILES COC
ChemSpider ID 7956
2D image http://www.chemspider.com/ImagesHandler.ashx?id=7956
Limits
Maximum temperature [K] 525.0
Maximum pressure [Pa] 50000000.0
Triple point
Triple point temperature [K] 131.66
Triple point pressure [Pa] 2.21072849111
Critical point
Critical point temperature [K] 400.378
Critical point density [kg/m3] 273.6465336
Critical point density [mol/m3] 5940.0
Critical point pressure [Pa] 5336800.0


REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/DimethylEther.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/DimethylEther1.png
