Ethane

References

Equation of State

D. Buecker and W. Wagner. A Reference Equation of State for the Thermodynamic Properties of Ethane for Temperatures from the Melting Line to 675 K and Pressures up to 900 MPa. J. Phys. Chem. Ref. Data, 35(1):205–266, 2006. doi:10.1063/1.1859286.

Thermal Conductivity

Daniel G. Friend, Hepburn Ingham, and James F. Ely. Thermophysical Properties of Ethane. J. Phys. Chem. Ref. Data, 20(2):275–347, 1991. doi:10.1063/1.555881.

Viscosity

Daniel G. Friend, Hepburn Ingham, and James F. Ely. Thermophysical Properties of Ethane. J. Phys. Chem. Ref. Data, 20(2):275–347, 1991. doi:10.1063/1.555881.

Melting Line

D. Buecker and W. Wagner. A Reference Equation of State for the Thermodynamic Properties of Ethane for Temperatures from the Melting Line to 675 K and Pressures up to 900 MPa. J. Phys. Chem. Ref. Data, 35(1):205–266, 2006. doi:10.1063/1.1859286.

Surface Tension

A. Mulero, I. Cachadiña, and M. I. Parra. Recommended Correlations for the Surface Tension of Common Fluids. J. Phys. Chem. Ref. Data, 41(4):043105–1:13, 2012. doi:10.1063/1.4768782.

Aliases

ethane, ETHANE, R170

Fluid Information

Parameter, Value
General
Molar mass [kg/mol] 0.03006904
CAS number 74-84-0
ASHRAE class A3
Formula \(C_{2}H_{6}\)
Acentric factor 0.099
InChI InChI=1/C2H6/c1-2/h1-2H3
InChIKey OTMSDBZUPAUEDD-UHFFFAOYAK
SMILES CC
ChemSpider ID 6084
2D image http://www.chemspider.com/ImagesHandler.ashx?id=6084
Limits
Maximum temperature [K] 675.0
Maximum pressure [Pa] 900000000.0
Triple point
Triple point temperature [K] 90.368
Triple point pressure [Pa] 1.14210763909
Critical point
Critical point temperature [K] 305.322
Critical point density [kg/m3] 206.180000007
Critical point density [mol/m3] 6856.886685
Critical point pressure [Pa] 4872200.0


REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/Ethane.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/Ethane1.png
