MDM

References

Equation of State

Monika Thol, Frithjof H. Dubberke, Elmar Baumhögger, Jadran Vrabec, and Roland Span. Speed of sound measurements and fundamental equations of state for octamethyltrisiloxane and decamethyltetrasiloxane. J. Chem. Eng. Data, 62(9):2633–2648, jul 2017. doi:10.1021/acs.jced.7b00092.

Surface Tension

A. Mulero and I. Cachadiña. Recommended Correlations for the Surface Tension of Several Fluids Included in the REFPROP Program. J. Phys. Chem. Ref. Data, 43:023104–1:8, 2014. doi:10.1063/1.4878755.

Aliases

Octamethyltrisiloxane, OCTAMETHYLTRISILOXANE

Fluid Information

Parameter, Value

General

Molar mass [kg/mol]

0.23653146

CAS number

107-51-7

ASHRAE class

UNKNOWN

Formula

\(C_{8}H_{24}O_{2}Si_{3}\)

Acentric factor

0.5280658490542447

InChI

InChI=1S/C8H24O2Si3/c1-11(2,3)9-13(7,8)10-12(4,5)6/h1-8H3

InChIKey

CXQXSVUQTKDNFP-UHFFFAOYSA-N

SMILES

C[Si](C)(C)O[Si](C)(C)O[Si](C)(C)C

ChemSpider ID

23101

2D image

http://www.chemspider.com/ImagesHandler.ashx?id=23101

Limits

Maximum temperature [K]

575.0

Maximum pressure [Pa]

130000000.0

Triple point

Triple point temperature [K]

187.2

Triple point pressure [Pa]

0.0010820636776824135

Critical point

Critical point temperature [K]

564.09

Critical point density [kg/m3]

256.739908797209

Critical point density [mol/m3]

1085.436621399999

Critical point pressure [Pa]

1410044.755816551

Reducing point

Reducing point temperature [K]

565.3609

Reducing point density [mol/m3]

1134.0

REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/MDM.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/MDM1.png
