MM¶

References¶

Equation of State¶

Monika Thol. Fundamental equation of state correlation for hexamethyldisiloxane based on experimental and molecular simulation data. Fluid Phase Equilib., 2015. doi:10.1016/j.fluid.2015.09.047.

Monika Thol. Empirical Multiparameter Equations of State Based on Molecular Simulation and Hybrid Data Sets. PhD thesis, Ruhr-Universität Bochum, 2015.

Surface Tension¶

A. Mulero and I. Cachadiña. Recommended Correlations for the Surface Tension of Several Fluids Included in the REFPROP Program. J. Phys. Chem. Ref. Data, 43:023104–1:8, 2014. doi:10.1063/1.4878755.

Aliases¶

Hexamethyldisiloxane, HEXAMETHYLDISILOXANE

Fluid Information¶

Parameter, Value
General
Molar mass [kg/mol] 0.16237752
CAS number 107-46-0
ASHRAE class UNKNOWN
Formula $$C_{6}H_{18}OSi_{2}$$
Acentric factor 0.418
InChI InChI=1/C6H18OSi2/c1-8(2,3)7-9(4,5)6/h1-6H3
InChIKey UQEAIHBTYFGYIE-UHFFFAOYAL
SMILES C[Si](C)(C)O[Si](C)(C)C
ChemSpider ID 23150
2D image
Limits
Maximum temperature [K] 673.0
Maximum pressure [Pa] 30000000.0
Triple point
Triple point temperature [K] 204.93
Triple point pressure [Pa] 2.95377013027
Critical point
Critical point temperature [K] 518.75
Critical point density [kg/m3] 258.151840734
Critical point density [mol/m3] 1589.825
Critical point pressure [Pa] 1939000.0
Reducing point
Reducing point temperature [K] 518.7
Reducing point density [mol/m3] 1653.0

REFPROP Validation Data¶

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form $$Y(T,\rho)$$, where $$Y$$ is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

Consistency Plots¶

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.
