R115¶

References¶

Equation of State¶

Eric W. Lemmon and Roland Span. Thermodynamic Properties of R-227ea, R-365mfc, R-115, and R13I1. J. Chem. Eng. Data, 2016, submitted. doi:10.1021/acs.jced.5b00684.

Fluid Information¶

Parameter, Value
General
Molar mass [kg/mol] 0.154466416
CAS number 76-15-3
ASHRAE class UNKNOWN
Formula $$C_{2}F_{5}Cl$$
Acentric factor 0.248434993066
InChI InChI=1/C2ClF5/c3-1(4,5)2(6,7)8
SMILES C(C(F)(F)Cl)(F)(F)F
ChemSpider ID 6190
2D image
Limits
Maximum temperature [K] 550.0
Maximum pressure [Pa] 60000000.0
Triple point
Triple point temperature [K] 173.57
Triple point pressure [Pa] 2178.23182836
Critical point
Critical point temperature [K] 353.1
Critical point density [kg/m3] 614.77633568
Critical point density [mol/m3] 3980.0
Critical point pressure [Pa] 3129036.96828

REFPROP Validation Data¶

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form $$Y(T,\rho)$$, where $$Y$$ is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

Consistency Plots¶

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.
