R123

References

Equation of State

Ben A. Younglove. An International Standard Equation of State for the Thermodynamic Properties of Refrigerant 123 (2,2-Dichloro-1,1,1-Trifluoroethane). J. Phys. Chem. Ref. Data, 23(5):731–779, 1994. doi:10.1063/1.555950.

Ideal gas specific heat

Ben A. Younglove. An International Standard Equation of State for the Thermodynamic Properties of Refrigerant 123 (2,2-Dichloro-1,1,1-Trifluoroethane). J. Phys. Chem. Ref. Data, 23(5):731–779, 1994. doi:10.1063/1.555950.

Thermal Conductivity

Arno Laesecke, Richard A. Perkins, and John B. Howley. An improved correlation for the thermal conductivity of HCFC123 (2,2-dichloro-1,1,1-trifluoroethane). Int. J. Refrig., 19(4):231–238, 1996. doi:10.1016/0140-7007(96)00019-9.

Viscosity

Y. Tanaka and T. Sotani. Thermal Conductivity and Viscosity of 2,2-Dichloro-1,1,1-Trifluoroethane (HCFC-123). Int. J. Thermophys., 17(2):293–328, 1996. doi:10.1007/BF01443394.

Surface Tension

A. Mulero, I. Cachadiña, and M. I. Parra. Recommended Correlations for the Surface Tension of Common Fluids. J. Phys. Chem. Ref. Data, 41(4):043105–1:13, 2012. doi:10.1063/1.4768782.

Fluid Information

Parameter, Value
General
Molar mass [kg/mol] 0.152931
CAS number 306-83-2
ASHRAE class B1
Formula \(C_{2}Cl_{2}F_{3}H\)
Acentric factor 0.281922497036
InChI InChI=1/C2HCl2F3/c3-1(4)2(5,6)7/h1H
InChIKey OHMHBGPWCHTMQE-UHFFFAOYAP
SMILES C(C(F)(F)F)(Cl)Cl
ChemSpider ID 9016
2D image http://www.chemspider.com/ImagesHandler.ashx?id=9016
Limits
Maximum temperature [K] 600.0
Maximum pressure [Pa] 76000000.0
Triple point
Triple point temperature [K] 166.0
Triple point pressure [Pa] 4.20213380244
Critical point
Critical point temperature [K] 456.831
Critical point density [kg/m3] 550.003648227
Critical point density [mol/m3] 3596.417
Critical point pressure [Pa] 3672000.0


REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/R123.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/R1231.png
