R13I1

References

Equation of State

Eric W. Lemmon and Roland Span. Thermodynamic Properties of R-227ea, R-365mfc, R-115, and R13I1. J. Chem. Eng. Data, 2016, submitted. doi:10.1021/acs.jced.5b00684.

Aliases

CF3I

Fluid Information

Parameter, Value
General
Molar mass [kg/mol] 0.1959104
CAS number 2314-97-8
ASHRAE class UNKNOWN
Formula \(CF_{3}I\)
Acentric factor 0.17618111777
InChI InChI=1/CF3I/c2-1(3,4)5
InChIKey VPAYJEUHKVESSD-UHFFFAOYAR
SMILES C(F)(F)(F)I
ChemSpider ID 15962
2D image http://www.chemspider.com/ImagesHandler.ashx?id=15962
Limits
Maximum temperature [K] 420.0
Maximum pressure [Pa] 50000000.0
Triple point
Triple point temperature [K] 120.0
Triple point pressure [Pa] 0.462374242725
Critical point
Critical point temperature [K] 396.44
Critical point density [kg/m3] 868.00061824
Critical point density [mol/m3] 4430.6
Critical point pressure [Pa] 3952566.07172


REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/R13I1.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/R13I11.png
