R23

References

Equation of State

Steven G. Penoncello, Eric W. Lemmon, Richard T Jacobsen, and Zhengjun Shan. A Fundamental Equation for Trifluoromethane (R-23). J. Phys. Chem. Ref. Data, 32(4):1473–1499, 2003. doi:10.1063/1.1559671.

Thermal Conductivity

Zhengjun Shan, Steven G Penoncello, and Richard T Jacobsen. A generalized model for viscosity and thermal conductivity of trifluoromethane (R-23). ASHRAE Transactions, 106:757, 2000.

Viscosity

Zhengjun Shan, Steven G Penoncello, and Richard T Jacobsen. A generalized model for viscosity and thermal conductivity of trifluoromethane (R-23). ASHRAE Transactions, 106:757, 2000.

Surface Tension

A. Mulero, I. Cachadiña, and M. I. Parra. Recommended Correlations for the Surface Tension of Common Fluids. J. Phys. Chem. Ref. Data, 41(4):043105–1:13, 2012. doi:10.1063/1.4768782.

Fluid Information

Parameter, Value

General

Molar mass [kg/mol]

0.07001385

CAS number

75-46-7

ASHRAE class

A1

Formula

\(CF_{3}H\)

Acentric factor

0.262964892496154

InChI

InChI=1S/CHF3/c2-1(3)4/h1H

InChIKey

XPDWGBQVDMORPB-UHFFFAOYSA-N

SMILES

C(F)(F)F

ChemSpider ID

21106179

2D image

http://www.chemspider.com/ImagesHandler.ashx?id=21106179

Limits

Maximum temperature [K]

475.0

Maximum pressure [Pa]

120000000.0

Triple point

Triple point temperature [K]

118.02

Triple point pressure [Pa]

58.04099416222911

Critical point

Critical point temperature [K]

299.293

Critical point density [kg/m3]

526.504152

Critical point density [mol/m3]

7519.999999999999

Critical point pressure [Pa]

4832000.0

REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/R23.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/R231.png
