n-Butane

References

Equation of State

D. Buecker and W. Wagner. Reference Equations of State for the Thermodynamic Properties of Fluid Phase n-Butane and Isobutane. J. Phys. Chem. Ref. Data, 35(2):929–1019, 2006. doi:10.1063/1.1901687.

Thermal Conductivity

R.A. Perkins, M.L.V. Ramires, C.A. Nieto de Castro, and L. Cusco. Measurement and Correlation of the Thermal Conductivity of Butane from 135 K to 600 K at Pressures to 70 MPa. J. Chem. Eng. Data, 47(5):1263–1271, 2002. doi:10.1021/je0101202.

Viscosity

E. Vogel, C. Kuechenmeister, and E. Bich. Viscosity for n-Butane in the Fluid Region. High Temp. - High Pressures, 31(2):173–186, 1999. doi:10.1068/htrt154.

Melting Line

D. Buecker and W. Wagner. Reference Equations of State for the Thermodynamic Properties of Fluid Phase n-Butane and Isobutane. J. Phys. Chem. Ref. Data, 35(2):929–1019, 2006. doi:10.1063/1.1901687.

Surface Tension

A. Mulero, I. Cachadiña, and M. I. Parra. Recommended Correlations for the Surface Tension of Common Fluids. J. Phys. Chem. Ref. Data, 41(4):043105–1:13, 2012. doi:10.1063/1.4768782.

Aliases

nButane, butane, BUTANE, N-BUTANE, R600

Fluid Information

Parameter, Value
General
Molar mass [kg/mol] 0.0581222
CAS number 106-97-8
ASHRAE class A3
Formula \(C_{4}H_{10}\)
Acentric factor 0.200810094644
InChI InChI=1/C4H10/c1-3-4-2/h3-4H2,1-2H3
InChIKey IJDNQMDRQITEOD-UHFFFAOYAE
SMILES CCCC
ChemSpider ID 7555
2D image http://www.chemspider.com/ImagesHandler.ashx?id=7555
Limits
Maximum temperature [K] 575.0
Maximum pressure [Pa] 12000000.0
Triple point
Triple point temperature [K] 134.895
Triple point pressure [Pa] 0.665658220808
Critical point
Critical point temperature [K] 425.125
Critical point density [kg/m3] 228.0
Critical point density [mol/m3] 3922.76961299
Critical point pressure [Pa] 3796000.0


REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/n-Butane.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/n-Butane1.png
