CarbonDioxide

References

Equation of State

R. Span and W. Wagner. A New Equation of State for Carbon Dioxide Covering the Fluid Region from the Triple Point Temperature to 1100 K at Pressures up to 800 MPa. J. Phys. Chem. Ref. Data, 25:1509–1596, 1996. doi:10.1063/1.555991.

Thermal Conductivity

M. L. Huber, E. A. Sykioti, M. J. Assael, and R. A. Perkins. Reference correlation of the thermal conductivity of carbon dioxide from the triple point to 1100 k and up to 200 mpa. Journal of Physical and Chemical Reference Data, 2016. doi:10.1063/1.4940892.

Viscosity

A. Laesecke and C. D. Muzny. Reference correlation for the viscosity of carbon dioxide. Journal of Physical and Chemical Reference Data, 2017. doi:10.1063/1.4977429.

Melting Line

R. Span and W. Wagner. A New Equation of State for Carbon Dioxide Covering the Fluid Region from the Triple Point Temperature to 1100 K at Pressures up to 800 MPa. J. Phys. Chem. Ref. Data, 25:1509–1596, 1996. doi:10.1063/1.555991.

Surface Tension

A. Mulero, I. Cachadiña, and M. I. Parra. Recommended Correlations for the Surface Tension of Common Fluids. J. Phys. Chem. Ref. Data, 41(4):043105–1:13, 2012. doi:10.1063/1.4768782.

Aliases

R744, co2, CO2, carbondioxide, CARBONDIOXIDE

Fluid Information

Parameter, Value

General

Molar mass [kg/mol]

0.0440098

CAS number

124-38-9

ASHRAE class

A1

Formula

\(CO_{2}\)

Acentric factor

0.22394

InChI

InChI=1S/CO2/c2-1-3

InChIKey

CURLTUGMZLYLDI-UHFFFAOYSA-N

SMILES

C(=O)=O

ChemSpider ID

274

2D image

http://www.chemspider.com/ImagesHandler.ashx?id=274

Limits

Maximum temperature [K]

2000.0

Maximum pressure [Pa]

800000000.0

Triple point

Triple point temperature [K]

216.592

Triple point pressure [Pa]

517964.34344772575

Critical point

Critical point temperature [K]

304.1282

Critical point density [kg/m3]

467.60000128174005

Critical point density [mol/m3]

10624.9063

Critical point pressure [Pa]

7377300.0

REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/CarbonDioxide.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as… or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/CarbonDioxide1.png
