R152A

References

Equation of State

Stephanie L. Outcalt and Mark O. McLinden. A Modified Benedict-Webb-Rubin Equation of State for the Thermodynamic Properties of R152a (1,1-difluoroethane). J. Phys. Chem. Ref. Data, 25(2):605–636, 1996. doi:10.1063/1.555979.

Thermal Conductivity

R. Krauss, I V. C. Weiss, T. A. Edison, J. V. Sengers, and K. Stephan. Transport Properties of 1,1-Difluoroethane (R152a). Int. J. Thermophys, 17:731–757, 1996. doi:10.1007/BF01439187.

Viscosity

Ian H. Bell and Arno Laesecke. Viscosity of refrigerants and other working fluids from residual entropy scaling . In 16th International Refrigeration and Air Conditioning Conference at Purdue, July 11-14, 2016. 2016.

Surface Tension

A. Mulero, I. Cachadiña, and M. I. Parra. Recommended Correlations for the Surface Tension of Common Fluids. J. Phys. Chem. Ref. Data, 41(4):043105–1:13, 2012. doi:10.1063/1.4768782.

Aliases

R152a

Fluid Information

Parameter, Value
General
Molar mass [kg/mol] 0.066051
CAS number 75-37-6
ASHRAE class A2
Formula \(C_{2}F_{2}H_{4}\)
Acentric factor 0.275217114532
InChI InChI=1/C2H4F2/c1-2(3)4/h2H,1H3
InChIKey NPNPZTNLOVBDOC-UHFFFAOYAM
SMILES CC(F)F
ChemSpider ID 6128
2D image http://www.chemspider.com/ImagesHandler.ashx?id=6128
Limits
Maximum temperature [K] 500.0
Maximum pressure [Pa] 58000000.0
Triple point
Triple point temperature [K] 154.56
Triple point pressure [Pa] 64.1386497369
Critical point
Critical point temperature [K] 386.411
Critical point density [kg/m3] 368.0
Critical point density [mol/m3] 5571.45236257
Critical point pressure [Pa] 4520000.0


REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/R152A.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/R152A1.png
