Propyne

References

Equation of State

Axel Polt, Bernhard Platzer, and Gerd Maurer. Parameter der thermischen Zustandsgleichung von Bender für 14 mehratomige reine Stoffe. Chem. Technik, 22:216–224, 1992.

Ideal gas specific heat

Axel Polt, Bernhard Platzer, and Gerd Maurer. Parameter der thermischen Zustandsgleichung von Bender für 14 mehratomige reine Stoffe. Chem. Technik, 22:216–224, 1992.

Surface Tension

A. Mulero, I. Cachadiña, and M. I. Parra. Recommended Correlations for the Surface Tension of Common Fluids. J. Phys. Chem. Ref. Data, 41(4):043105–1:13, 2012. doi:10.1063/1.4768782.

Aliases

propyne, PROPYNE

Fluid Information

Parameter, Value
General
Molar mass [kg/mol] 0.04006
CAS number 74-99-7
ASHRAE class UNKNOWN
Formula \(C_{3}H_{4}\)
Acentric factor 0.204
InChI InChI=1/C3H4/c1-3-2/h1H,2H3
InChIKey MWWATHDPGQKSAR-UHFFFAOYAI
SMILES CC#C
ChemSpider ID 6095
2D image http://www.chemspider.com/ImagesHandler.ashx?id=6095
Limits
Maximum temperature [K] 474.0
Maximum pressure [Pa] 31800000.0
Triple point
Triple point temperature [K] 273.0
Triple point pressure [Pa] 263566.905988
Critical point
Critical point temperature [K] 402.38
Critical point density [kg/m3] 244.8999998
Critical point density [mol/m3] 6113.33
Critical point pressure [Pa] 5626000.0


REFPROP Validation Data

Note

This figure compares the results generated from CoolProp and those generated from REFPROP. They are all results obtained in the form \(Y(T,\rho)\), where \(Y\) is the parameter of interest and which for all EOS is a direct evaluation of the EOS

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/Propyne.png

Consistency Plots

The following figure shows all the flash routines that are available for this fluid. A red + is a failure of the flash routine, a black dot is a success. Hopefully you will only see black dots. The red curve is the maximum temperature curve, and the blue curve is the melting line if one is available for the fluid.

In this figure, we start off with a state point given by T,P and then we calculate each of the other possible output pairs in turn, and then try to re-calculate T,P from the new input pair. If we don’t arrive back at the original T,P values, there is a problem in the flash routine in CoolProp. For more information on how these figures were generated, see CoolProp.Plots.ConsistencyPlots

Note

You can download the script that generated the following figure here: (link to script), right-click the link and then save as... or the equivalent in your browser. You can also download this figure as a PDF.

../../_images/Propyne1.png
